Series PHF BS2 R20 High Flow
Model PHF BS2 R20 · Pipeline Regulators
Brass body pipeline regulator offering balanced-valve stability and high flow performance with 2 inch NPT ports.
Maximum Inlet Pressure60 bar
Setting Range0.2 to 3 / 0.5 to 8 / 1.5 to 15 / 2 to 30 / 3 to 50 bar
In/Out Connections1 1/2 and 2 in (G-F / NPT-F)
Key features
- 2 inch line size, Kv 25 m3/h for distribution mains
- Five setting ranges covering 0.2 to 50 bar
- Self actuated, no external power or air needed
- Brass body with stainless steel internals
- Oxygen-degreased version available
Enquire about this product
Priced to your specification. Most enquiries are answered the same working day.
Request a quoteUK stock and next-day dispatch on held lines
Technical selection support before you order
The full bore unit of the brass pipeline family, in 1 1/2 and 2 inch line sizes with a 25 m3/h flow capacity for main distribution runs. Five setting ranges cover 0.2 to 50 bar from a 60 bar inlet, self actuated with no pneumatic or electrical connection needed. Brass body with stainless steel internals, and a degreased version is available for oxygen service.
Conformity
PED 2014/68/EU
Specification
| Maximum Inlet Pressure | 60 bar |
|---|---|
| Setting Range | 0.2 to 3 / 0.5 to 8 / 1.5 to 15 / 2 to 30 / 3 to 50 bar |
| In/Out Connections | 1 1/2 and 2 in (G-F / NPT-F) |
| Temperature | -20 to +80 C |
| Weight | 4.3 kg |
| Inner Parts | stainless steel |
| Body Material | brass |
| Kv (EN 60534) | 25 m3/h |
Gases
Hydrogen
