Series PHF CS2 R10 High Flow
Model PHF CS2 R10 · Pipeline Regulators
Pipeline regulator offering balanced-valve stability and high flow performance with 3/4-1 inch NPT ports.
Maximum Inlet Pressure60 bar
Setting Range0.3 to 3 / 0.8 to 8 / 1.5 to 15 / 3 to 30 / 5 to 50 bar
In/Out Connections3/4 and 1 in (G-F / NPT-F); flanged available
Key features
- Full AISI 316L body and internals
- Five setting ranges spanning 0.3 to 50 bar
- Service temperatures to +200 C with FPM seals
- Threaded, flanged or clamp connections
- ATEX and PED certified
Enquire about this product
Priced to your specification. Most enquiries are answered the same working day.
Request a quoteUK stock and next-day dispatch on held lines
Technical selection support before you order
A stainless steel pipeline regulator in 3/4 and 1 inch sizes for duties brass cannot carry: corrosive gases, process lines and temperatures up to +200 C with FPM seals. Five setting ranges span 0.3 to 50 bar from a 60 bar inlet, with balanced valve stability under changing flow. Threaded, flanged or clamp connections, ATEX certified alongside PED.
Conformity
PED 2014/68/EU; ATEX 2014/34/EU
Specification
| Maximum Inlet Pressure | 60 bar |
|---|---|
| Setting Range | 0.3 to 3 / 0.8 to 8 / 1.5 to 15 / 3 to 30 / 5 to 50 bar |
| In/Out Connections | 3/4 and 1 in (G-F / NPT-F); flanged available |
| Temperature | -25 to +200 C (FPM seals) / -40 to +175 C (EPDM) |
| Weight | 4.5 kg |
| Inner Parts | AISI 316L stainless steel |
| Body Material | AISI 316L stainless steel |
| Kv (EN 60534) | 8.5 m3/h |
Gases
Hydrogen
Downloads
No documents on file for this product yet.
