D131 Pneumatic Actuated Valve For Corrosive Gases.
Model D131 · Tied diaphragm seal type
Pneumatic cylinder Valve with Packed Needle Stem Design for High Purity Gas Applications.
Orifice2.8 mm
Maximum Inlet Pressure200 bar
In/Out Connectionsto national or international standards and customer specification
Cv0.25
Key features
- Pneumatic actuator, packed stem
- 2.8 mm orifice, 200 bar, Cv 0.25
- Gas kept from the operating mechanism
- Stainless, bronze or brass bodies
Enquire about this product
Priced to your specification. Most enquiries are answered the same working day.
Request a quoteUK stock and next-day dispatch on held lines
Technical selection support before you order
The pneumatically actuated packed type cylinder valve for high purity corrosive gases, rated 200 bar with a 2.8 mm orifice and Cv 0.25, for installations where the cylinder is opened and closed remotely. It shares the packed valve principle in which the gas does not reach the operating mechanism, so the valve stays free from seizure in corrosive service, with replaceable internal parts and a low internal volume for inert purging. Bodies in AISI 303 or 316L stainless steel, aluminium silicon bronze or brass, marked to TPED.
Specification
| Orifice | 2.8 mm |
|---|---|
| Maximum Inlet Pressure | 200 bar |
| In/Out Connections | to national or international standards and customer specification |
| Cv | 0.25 |
| Temperature | -20 to +65 C |
| Body Material | AISI 303 or AISI 316L stainless steel, aluminium silicon bronze or brass |
| Technology | pneumatically actuated packed type cylinder valve |
